Name 2018 BEIJING INTERNATIONAL AUTOMOTIVE EXHIBITION
Exhibition Theme Steering To A New Era
Venue New China International Exhibition Center (Tianzhu, Shunyi) Add: 88 Yuxiang Road, Tianzhu, Shunyi District, Beijing
Participation Theme Car Drives Dream
Media Day April 25, 2018 09:00-18:00 Media and guests
April 26, 2018 10:00-18:00 Media and guests
Professional Day April 27-28, 2018 10:00-18:00 Professional visitors
Public Day April 29-May 3, 2018 10:00-18:00 The public and professional visitors
May 4, 2018 10:00-15:00 The public and professional visitors
Dongfeng Brand Strategy Release Conference
Dongfeng Brand Strategy Release Conference
2018 Beijing International Automotive Exhibition

01

New Brand, New Image-DFM makes brilliant appearance at Auto China 2018
"Steering To A New Era" Auto China 2018 opened on April 25. Under the theme of "Car Drives Dream"...
"Steering To A New Era" Auto China 2018 opened on April 25...
A9
AX7
AX4
A60 RACE CAR
E70
T5
S50EV
M7
M6
M5EV
iX5
Glory 580
Glory 580PHEV
Glory S560
DFM Mengshi
Succe
DFMC 10TD engine
DFMA14T-48V engine
6DCT 150
windlink3.0
Steering To A New Era
Chairman Zhu Yanfeng delivers a speech

02

President Li Shaozhu introduces the brand concept

02

Dongfeng Brand Strategy Release Conference

02

Launch of windlink AI system

02

Launch of windlink AI system

02

Launch of DFM eπ new energy concept car

02

Launch of DFM eπ new energy concept car

02

scene

02

scene

02

scene

02

scene

02

scene

02

scene

02

Launch of DFM FurterLink T5

02

Exhibit Name A9
Exhibit Description A9 is the product after DFM half century of efforts in lean production. As a high-end passenger car independently developed by DFM with independent property rights, it provides for customers an elegant choice with super experience by virtue of its elegant overall design, excellent intelligent technology, over-class driving experience and strong and high-efficient powertrain.
Main technical parameters
Length * Width * Height (mm) A9 Engine displacement (ml) 1751
Wheelbase (mm) 2900 Aspiration Turbocharged
Front / rear track width (mm) 1589/1563 Compression ratio 7.9
Minimum ground clearance (mm) 120 (full load) Bore * stroke (mm*mm) 77.5*92.8
Curb weight (kg) 1660 Maximum power (kw/rpm) 150/5500
Fuel tank volume (L) 70 Maximum torque (N·m/rpm) 280/1400-4000
Trunk capacity (L) 500 Transmission type 6-speed Tiptronic transmission
Rated seating capacity (person) 5 Number of gears 6
Maximum speed (KM/h) 230 Drive mode FF
0-100km/h acceleration time (S) 8.5 (ODM) Front suspension type McPherson independent suspension
Combined fuel consumption (L/100km) 6.6 Rear suspension type Multi-link independent suspension
Emission standard Euro V Steering assistance method Electrohydraulic variable power steering
Engine model 10UF516G01 Tire specification 18 inch aluminum wheel
Color
Exhibit Name AX7
Exhibit Description DFM AX7 is the product from 4 years of efforts by DFM Technology Center, which inherits DFM’s commitment of “Self Development, Independent Development, Independent Innovation” and integrates DFM’s half century of auto-making experience and above 20 years of joint venture experience. It was built from DFM’s No. 2 military platform, and has won the wide market acceptance with an accumulated users up to 200,000 persons since its launch in November, 2014. The DFM new AX7 launched on December 21, 2017 has gotten more than 135 elements upgraded, and boasts 4 advantages including new appearance, new quality, new power and new wisdom.
Main technical parameters
Length * Width * Height (mm) 4696*1850*1712 Engine displacement (ml) 1598
Wheelbase (mm) 2712 Aspiration Turbocharged
Front / rear track width (mm) 1585/1585 Compression ratio 9.2
Minimum ground clearance (mm) 190 (no load) Bore * stroke (mm*mm) 77*85.8
Curb weight (kg) 1565 Maximum power (kw/rpm) 123
Fuel tank volume (L) 60 Maximum torque (N·m /rpm) 245
Trunk capacity (L) 565/1572 Transmission type Tiptronic
Rated seating capacity (person) 5 Number of gears 6
Maximum speed (KM/h) 185 Drive mode FF
0-100km/h acceleration time (S) 10.8 Front suspension type McPherson independent suspension
Combined fuel consumption (L/100km) 7 Rear suspension type Double-wishbone independent suspension
Emission standard Euro V Steering assistance method Electric power steering
Engine model 10UF01 5G02 Tire specification 225/60 R18
Color Silk silver
Exhibit Name AX4
Exhibit Description AX4 is the first high-end compact SUV in the Aeolus family, which enriches the Aeolus SUV portfolio together with AX7, AX5 and AX3. It is the forerunner of DFM’s 3.0 strategy, promoting the upgrading of Aeolus development strategy. Targeted to the generation after 90s who are characterized by vigor and progression, AX4 is tailored on the preferences, personality and needs of this target population.
Main technical parameters
Length * Width * Height (mm) 4195*1780*1622 Engine displacement (ml) 1396
Wheelbase (mm) 2580 Aspiration Turbocharged
Front / rear track width (mm) 1490/1510 Compression ratio 8.9
Minimum ground clearance (mm) 185 (no load) Bore * stroke (mm*mm) 73*83.4
Curb weight (kg) 1321 Maximum power (kw/rpm) 103/5500
Fuel tank volume (L) 45 Maximum torque (N·m /rpm) 196/1800-4500
Trunk capacity (L) 278/609 Transmission type Wet dual clutch
Rated seating capacity (person) 5 Number of gears 6
Maximum speed (KM/h) 177 Drive mode Front drive
0-100km/h acceleration time (S) 12 Front suspension type McPherson independent suspension
Combined fuel consumption (L/100km) 6.5 Rear suspension type Torsion beam semi-independent suspension
Emission standard Euro V Steering assistance method Electric power steering
Engine model DFM A14T Tire specification 215/50 R17
Color Flowing red and black (double color)
Exhibit Name A60 RACE CAR
Exhibit Description A60 Race Car is jointly designed by DFM Technology Center and Swedish T company, a wholly-owned overseas R&D agency of DFM. The turbocharging and full-time four-wheel drive technology gives higher power, the carbon fiber material makes the body lighter, the Northern Europe-level chassis tuning makes the vehicle more agile, the FIA approved roll cage allows high safety, and the 3D printing package allows for accommodating the future technology development.
A60 Race Car is a member of the Aeolus fleet. This fleet is the first racing team under Dongfeng self-owned brand in which the first-line engineers serves as both racer and designer, and it has made outstanding achievements in China's mainstream event 2017. In the future, the racing genes represented by the A60 RACE CAR will injects more passion and vitality into Dongfeng Brand.
Main technical parameters
Length * Width * Height (mm) 4680*1920*1415 Engine model EW10
Wheelbase (mm) 2700 Engine displacement (ml) 2000
Front / rear track width (mm) 1625/1625 Aspiration Turbocharged
Minimum ground clearance (mm) 80 Maximum power (kw/rpm) 300/6200
Curb weight (kg) 1060 Maximum torque (N·m /rpm) 520/4800
Fuel tank volume (L) 40 Transmission type MT
Rated seating capacity (person) 2 Number of gears 5
Maximum speed (KM/h) 280 Drive mode Full-time 4WD
0-100km/h acceleration time (S) 4 Front / rear suspension type McPherson / Multi-link
100-0km/h braking distance 33.5 Steering assistance method Electric power steering
Maximum lateral acceleration (g) 1.13 Tire specification 295/30 R18
Color Red
Exhibit Name E70
Exhibit Description DFM E70 is equipped with the drive motor, motor controller and vehicle control system independently developed by DFM, the high-density and high-capacity battery allowing a range over 350km, and the brand-new windlink2.0 plus system and 10.4-inch LCD. The battery can be charged to 100% capacity by 6-8h of slow charging, and to 80% capacity by only half an hour of fast charging.
Main technical parameters
Length * Width * Height (mm) 4680*1720*1530
Wheelbase (mm) 2700
Front / rear track width (mm) 1475/1480
Minimum ground clearance (mm) 120
Curb weight (kg) 1564
Rated seating capacity (person) 5
Battery type Li(NiCoMn)O2 battery
Battery capacity (kWh) 49
Transmission type Single-speed gearbox
Motor type Permanent magnet synchronous motor
Motor power (rated / peak) (kW) 42/90
Motor torque (rated / peak) (N·m) 100/260
Range per charging (KM) 350
Maximum speed (KM/h) 145
Charging time (fast / slow) (h) 0.5/6-8
Color White marble
Exhibit Name T5
Exhibit Description DFM T5, as the first model marking the birth of DFM 3.0 strategy which is defined to know you better, features 4 highlights including high appearance, high intelligence, high sociability and high ability. For the exteriors, it is applied with the integrated design and the C-pillar floating roof. For the interiors, it is equipped with the surrounding dashboard, 12.3-inch high-definition full-color LCD instrument panel and the 11.8-inch large-screen high-definition central control display. For the power, the matching of 1.6TD direct injection engine with dual clutch transmission together with the application of TVDI technology realize higher torque at lower speed and an improved fuel efficiency. For the intelligence, the "All in Car" intelligent ecosystem enables global voice manipulation and cross-scenario functional links before and after driving, and will bring a truly intelligent car experience to users.
Main technical parameters
Length * Width * Height (mm) 4530*1812*1725 Engine displacement (ml) 1598
Wheelbase (mm) 2700 Aspiration Turbocharged
Front / rear track width (mm) 1540/1545 Compression ratio 10.5
Minimum ground clearance (mm) 200 Bore * stroke (mm*mm) 77*85.8
Curb weight (kg) 1585 Maximum power (kw/rpm) 142
Fuel tank volume (L) 55 Maximum torque (N·m /rpm) 270
Trunk capacity (L) 515 Transmission type DCT
Rated seating capacity (person) 5 Number of gears 7
Maximum speed (KM/h) 180 Drive mode FF
0-100km/h acceleration time (S) 11 Front suspension type McPherson independent suspension
Combined fuel consumption (L/100km) 8 Rear suspension type Multi-link independent suspension
Emission standard Euro V Steering assistance method Electric power steering
Engine model CE16 Tire specification 215/55 R18
Color Glass red
Exhibit Name S50EV
Exhibit Description DFM S50EV is the first electric car of FurterLink family. It features strong power, high-efficiency acceleration, a max. speed of 150km/h and a combined range of 250km, and perfectly integrates nimble control, comfortable riding, high safety and low noise, with all performances up to the industry-wise advanced level.
Main technical parameters
Length * Width * Height (mm) 4665*1790*1526
Wheelbase (mm) 2700
Front / rear track width (mm) 1540/1545
Minimum ground clearance (mm) 150
Curb weight (kg) 1540
Rated seating capacity (person) 5
Battery type Li(NiCoMn)O2 battery
Battery capacity (kWh) 38.09
Transmission type Single-speed constant ratio
Motor type Permanent magnet synchronous motor
Motor power (rated / peak) (kW) 40/90
Motor torque (rated / peak) (N·m) 280
Range per charging (KM) 255
Maximum speed (KM/h) 150
Charging time (fast / slow) (h) 0.75/6
Color Pearl White
Exhibit Name M7
Exhibit Description DFM M7, a model with brand-new and magnificent business appearance redesigned on the basis of DFM CM7, is China's first self-developed high-end MPV positioned at first-class commercial vehicle segment. It is featured with such highlights as fashion styling, spacious and comfortable riding experience and excellent safety performance, fully reflecting the perfect combination of Human, Vehicle and Business. Since its debut in 2013, it has become the designated vehicle brand for large official and commercial events like ASEAN Expo, defining a new benchmark for high-end commercial vehicle of self-owned brand.
Main technical parameters
Length * Width * Height (mm) 5150*1920*1925 Engine displacement (ml) 1997
Wheelbase (mm) 3198 Aspiration Turbocharged
Front / rear track width (mm) 1685/1660 Compression ratio 9.3
Minimum ground clearance (mm) / Bore * stroke (mm*mm) 85*88
Curb weight (kg) 2120 Maximum power (kw/rpm) 140/5500
Fuel tank volume (L) 75 Maximum torque (N·m /rpm) 250/2400-4400
Trunk capacity (L) / Transmission type AT
Rated seating capacity (person) 7 Number of gears 6
Maximum speed (KM/h) 170 Drive mode Front Engine/Rear Drive (FR)
0-100km/h acceleration time (S) / Front suspension type L-shaped arm MacPherson independent suspension
Combined fuel consumption (L/100km) 10.6 Rear suspension type Multi-link independent suspension
Emission standard Euro V Steering assistance method Electric power steering
Engine model 4G63T Tire specification 225/55 R17
Color Pearl White
Exhibit Name M6
Exhibit Description M6 is a model redesigned on the basis of F600 with brand-new exteriors and interiors, and is launched as the innovative product of the middle-end commercial vehicle segment. Integrating common design elements of high-end commercial vehicle, this model perfectly combines “Human, Vehicle and Business” elements to adapt to the ever-changing and upgraded market demands for middle-end commercial vehicle, leading the innovative development of middle-end commercial vehicle segment, and   setting off the upgrading tide of middle-end commercial vehicles.
Main technical parameters
Length * Width * Height (mm) 5080*1770*1915 Engine displacement (ml) 1499
Wheelbase (mm) 3200 Aspiration Turbocharged
Front / rear track width (mm) 1525/1500 Compression ratio 9.5
Minimum ground clearance (mm) / Bore * stroke (mm*mm) 75*84.8
Curb weight (kg) 1795 Maximum power (kw/rpm) 100/5600
Fuel tank volume (L) 55 Maximum torque (N·m /rpm) 200/2000-4400
Trunk capacity (L) / Transmission type MT
Rated seating capacity (person) 7 Number of gears 6
Maximum speed (KM/h) 150 Drive mode Front Engine/Rear Drive (FR)
0-100km/h acceleration time (S) 16 Front suspension type McPherson independent suspension
Combined fuel consumption (L/100km) 8.9 Rear suspension type Coil spring
Emission standard Euro V Steering assistance method Hydraulic power steering
Engine model 4A91T Tire specification 215/60 R16
Color Tektite black
Exhibit Name M5EV
Exhibit Description DFM M5EV, a model developed on the basis of M5, is equipped with the independently developed front-engine & rear-drive electric drive system, which allows for strong and high-efficient power, a 0-50 km/h acceleration time below 5s, a maximum speed above 120 km/h and NEDC range above 200 km. Featured with high economical efficiency, good environmental friendliness, low operation cost and high versatility, it meets the demands for touring, commuting and urban logistics.
Main technical parameters
Length * Width * Height (mm) 5145*1720*1980
Wheelbase (mm) 3000
Front / rear track width (mm) 1445/1420
Minimum ground clearance (mm) 180
Curb weight (kg) 1880
Rated seating capacity (person) 6
Battery type Li(NiCoMn)O2 battery
Battery capacity (kWh) 40.4
Transmission type Single-speed constant ratio
Motor type Permanent magnet synchronous motor
Motor power (rated / peak) (kW) 40/80
Motor torque (rated / peak) (N·m) 450
Range per charging (KM) 200
Maximum speed (KM/h) 120
Charging time (fast / slow) (h) 2/8
Color Pearl White
Exhibit Name iX5
Exhibit Description As an intelligent coupé SUV, DFM iX5 not only suggests the development trend of SUV, and enjoys the soft power for intelligent development and iterative upgrading. The intelligent three-screen layout creates an immersive atmosphere; the brand-new smart link system allows for self-adaptive iterative based on technology upgrades; the FCW (forward collision warning) and LDW (lane departure warning) system can help drivers to comprehensively judge the road conditions; the 1.5T GDI engine provides super-high power and ultra-low fuel consumption; and the precision-tuned chassis ensures both maneuverability and comfort.
Main technical parameters
Length * Width * Height (mm) 4995*1865*1645 Engine displacement /
Wheelbase (mm) 2790 Aspiration /
Front / rear track width (mm) 1580/1575 Compression ratio /
Minimum ground clearance (mm) 195 Bore * stroke (mm*mm) /
Curb weight (kg) 1630 Maximum power (kw/rpm) /
Fuel tank volume (L) 58 Maximum torque (N·m /rpm) /
Trunk capacity (L) 379-796 Transmission type CVT
Rated seating capacity (person) 5 Number of gears /
Maximum speed (KM/h) / Drive mode /
0-100km/h acceleration time (S) / Front suspension type /
Combined fuel consumption (L/100km) / Rear suspension type /
Emission standard Euro VI Steering assistance method /
Engine model / Tire specification 235/45 R19
Color Melbourne red
Exhibit Name Glory 580
Exhibit Description Glory 580 SmartLink, which is defined as a super-city SUV, is the premium version of current Glory 580 portfolio, is the first model developed under the "Super Smart” strategy. The Glory 580 SmartLink stands out in the market by virtue of its advanced smart link technology of Lin OS 3.0 system, which provides more than 40 functions such as voice control, remote control, and entertainment, and brings users more interactive and intelligent experience.
Main technical parameters
Length * Width * Height (mm) 4680*1845*1715 Engine displacement (ml) 1498
Wheelbase (mm) 2780 Aspiration Turbocharged
Front / rear track width (mm) 1570/1572 Compression ratio 9.2:1
Minimum ground clearance (mm) 200 Bore * stroke (mm*mm) 75*84.8
Curb weight (kg) 1510 Maximum power (kw/rpm) 110/5600
Fuel tank volume (L) 58 Maximum torque (N·m /rpm) 220/1800-4000
Trunk capacity (L) 152-866 Transmission type CVT
Rated seating capacity (person) 7 Number of gears Not available
Maximum speed (KM/h) 180 Drive mode FF
0-100km/h acceleration time (S) / Front suspension type McPherson independent suspension
Combined fuel consumption (L/100km) 7.2 Rear suspension type Torsion beam dependent suspension
Emission standard Euro V Steering assistance method Electric power steering
Engine model SFG 15T Tire specification 225/55 R18
Color Emperor blue
Exhibit Name Glory 580PHEV
Exhibit Description Glory 580PHEV is a plug-in hybrid SUV built on the basis of the Glory 580. The matching of 1.8L engine + dual motor power combination with E-CVT intelligent automatic transmission system enables various power output modes including pure electric mode and hybrid mode. The model can be charged by the household 220V power supply, and is suitable for both short-distance and long-distance trips, meeting the demands of different populations.
Main technical parameters
Length * Width * Height (mm) 4680*1845*1715
Wheelbase (mm) 2780
Front / rear track width (mm) 1570/1572
Minimum ground clearance (mm) 175
Curb weight (kg) 1740
Rated seating capacity (person) 5/7
Battery type Lithium-ion battery
Battery capacity (kWh) 12.69
Transmission type E-CVT
Motor type Permanent magnet synchronous motor
Motor power (rated / peak) (kW) Motor 1: 32/46; Motor 2: 45/68
Motor torque (rated / peak) (N·m) Motor 1: 72/93; Motor 2: 159/246
Range per charging (KM) 900
Maximum speed (KM/h) 180
Charging time (fast / slow) (h) 4H (slow charging)
Color Elegant white
Exhibit Name Glory S560
Exhibit Description Glory S560 SmartLink boasts 3 core advantages including convenient link, easy driving and super warranty. The practical, easy-to-use and reliable basic smart-link platform provides personalized functions such as real-time navigation, on-line entertainment, and remote control. This series of vehicle is equipped with ESP (Electronic Stability Program) and the electric speed-sensing power steering system, so that the maneuverability of the body can be guaranteed, and the overall regulation effect of suspension is more comfortable. Nearly 30 storage spaces are designed to better cater for the customer's needs for daily storage. DFM Glory 560 carries over the super-long warranty period of Glory brand, namely, 7 years / 150,000 kilometers, providing consumers with the most sincere quality assurance policy.
Main technical parameters
Length * Width * Height (mm) 4515*1815*1735 Engine displacement (ml) 1798
Wheelbase (mm) 2690 Aspiration Naturally aspirated
Front / rear track width (mm) 1540/1530 Compression ratio 10.2:1
Minimum ground clearance (mm) 200 Bore * stroke (mm*mm) 19.3*91.5
Curb weight (kg) 1440 Maximum power (kw/rpm) 102
Fuel tank volume (L) 50 Maximum torque (N·m /rpm) 187
Trunk capacity (L) 108-758 Transmission type CVT
Rated seating capacity (person) 5/7 Number of gears Not available
Maximum speed (KM/h) / Drive mode FF
0-100km/h acceleration time (S) / Front suspension type McPherson independent suspension
Combined fuel consumption (L/100km) 7.5 Rear suspension type Five-link coil spring driven axle
Emission standard Euro V Steering assistance method Electric power steering
Engine model SFG 18 Tire specification 215/60 R17
Color Symphony silver
Exhibit Name DFM Mengshi
Exhibit Description The CSK131A armored command vehicle built by Dongfeng Off-road Vehicle Co., Ltd. is an infantry fighting vehicle suitable for rapid deployment, mobility, assault and other battlefield missions, well representing the current military technology level of Dongfeng Motor.
Main technical parameters
Length * Width * Height (mm) 4975*2390*1900 Engine displacement (ml) 4500
Wheelbase (mm) 3300 Aspiration Turbocharged and turbocharged & intercooled
Front / rear track width (mm) 1913/1917 Compression ratio /
Minimum ground clearance (mm) 400 Bore * stroke (mm*mm) 107*124
Curb weight (kg) 4900 Maximum power (kw/rpm) 147
Fuel tank volume (L) 56+50 Maximum torque (N·m /rpm) 570/1500
Trunk capacity (L) / Transmission type Five-speed mechanical manual transmission
Rated seating capacity (person) 6 Number of gears 6
Maximum speed (KM/h) 120 Drive mode 4*4
0-100km/h acceleration time (S) / Front suspension type Double-wishbone independent suspension
Combined fuel consumption (L/100km) 19 Rear suspension type Double-wishbone independent suspension
Emission standard Euro IV Steering assistance method Hydraulic power steering system
Engine model ISDe200-41 Tire specification 305/80 R18
Color Digital camouflage
Exhibit Name Succe
Exhibit Description Through upgrading of hardware and software (ESC , EPS , VCU, etc.), and configuration of various advanced sensors including millimeter-wave radar, smart camera and laser radar, the positioning system with HD map, and the autopilot controller, the Succe BEV is able to realize real-time sensing of obstacles and perceived targets within 200 meters and a series of autonomous functions including autonomous route planning, lane change and obstacle avoidance by autonomous planning and decision-making, and also autonomous parking.
Main technical parameters
Length * Width * Height (mm) 4500*1695*1870
Wheelbase (mm) 2695
Front / rear track width (mm) 1470/1475
Minimum ground clearance (mm) 140
Curb weight (kg) 1720
Rated seating capacity (person) 5/7
Battery type Li(NiCoMn)O2 power cell
Battery capacity (kWh) 49.572
Transmission type Constant ratio
Motor type Permanent magnet synchronous motor
Motor power (rated / peak) (kW) 30/60
Motor torque (rated / peak) (N·m) 95/220
Range per charging (KM) 301
Maximum speed (KM/h) 120
Charging time (fast / slow) (h) 2.5/18
Color White
Exhibit Name DFMC 10TD engine
Exhibit Description The DFMC 10TD engine is the first three-cylinder small-displacement turbocharged direct-injection gasoline engine developed by Dongfeng based on the concept of platformization and modularization. It is applied with the low-inertia turbocharger, direct injection, middle intake and exhaust VVT, integrated exhaust manifold, variable displacement oil pump, dual mass flywheel, thermal management, friction reduction and other advanced technology, and features strong power, energy saving, environmental friendliness, low noise, high comfort, and good durability and reliability, with comprehensive performance up to the leading level among products of the same class.
Main technical parameters
Type In-line, 3-cylinder, 4-stroke, DOHC, turbocharged, direct injection
Bore * stroke (mm) 73*79.6
Displacement (ml) 999
Rated power 95/5500
Maximum torque (Nm /rpm) 196 / (1500-4500)
Low torque (Nm /rpm) 115/1000
Compression ratio 9.8:1
Minimum specific fuel consumption (by universal characteristic curve) (g/kWh) ≤235
Emission Euro VI or above
Exhibit Name DFMA14T-48V engine
Exhibit Description The DFMA14T-48V engine is the first 48V-system matched small-displacement turbocharged gasoline engine independently developed by Dongfeng. It is applied with BSG, 48V system control technology, and functions including automatic start/stop, power assistance, and brake energy recovery, reducing the NEDC fuel consumption rate by 10%, and enabling an emission in compliance with the Euro VI standard or above.
Main technical parameters
Type In-line, 3-cylinder, 4-stroke, DOHC, turbocharged, direct injection
Bore * stroke (mm) 73*79.6
Displacement (ml) 1396
Rated power 103/5500
Maximum torque (Nm /rpm) 196 / (1800-4500)
Low torque (Nm /rpm) 120/1200
Compression ratio 8.9:1
Minimum specific fuel consumption (by universal characteristic curve) (g/kWh) ≤245
BSG peak power (kW) 12
BSG peak torque (Nm /rpm) 55 / (0-1500)
Emission Euro VI or above
Exhibit Name 6DCT 150
Exhibit Description 6DCT150 is the third-generation light-weight compact dual-clutch transmission equipped with cascade gear and intelligent execution system, and its transmission efficiency, fuel economy, shifting comfort and other performances are up to the leading level among the products of same class.
Main technical parameters
Maximum input speed (rpm) 7000
Maximum torque (Nm /rpm) 190
Weight (dry weight) kg 57
Installation length (mm) 350
Input shaft to differential center distance (mm) 170
1st gear ratio 13-18.5
Speed ratio range 4.6-8.0
Transmission fluid (L) 3.5
Exhibit Name
Exhibit Description eπ Concept is the latest product of DFM’s 5-actions, namely, light weighting, motorizing, intelligentizing, networking and sharing. It is configured with the advanced intelligent system, enabling you to realize human machine interaction by language interaction and gesture recognition in the intelligent cabin. The automatic driving mode and manual driving mode are provided for user's choice. Besides, it creates for users a IoT smart city, and makes each trip convenient by providing users with dynamic information sharing and personalized configuration sharing, optimal route option, remote diagnosis, family interaction, and recommended hot points along the route. What's more, it features an all electric range of 400 km (after 15 min charging), a combined range (PHEV) of 1000km and a 0-100KM/h acceleration time below 4s, allowing the future users to experience every trip as the most perfect one.
Main technical parameters
Length * Width * Height (mm) 4549*2072*1336
Wheelbase (mm) 2765
Front / rear track width (mm) 1625/1625
Minimum ground clearance (mm) /
Curb weight (kg) ≈2100kg
Rated seating capacity (person) 4
Battery type /
Battery capacity (kWh) /
Transmission type /
Motor type /
Motor power (rated / peak) (kW) /
Motor torque (rated / peak) (N·m) /
Range per charging (KM) /
Maximum speed (KM/h) /
Charging time (fast / slow) (h) /
Color Silver gray
